Key features
- Electronic control via TouchControl
- Interval operation
Design
- Designed for wall mounted installation
- 90 cm wide
- Black
Features
- TouchControl with Electronic display
- 4-speed + intensive operation
- Automatic intensive revert (6mins)
- Automatic after running: 15 min
- Rim ventilation
- 2 x 1W LED
- Florescent mood lighting
- Light Colour: warm white
- 3 removable metal grease filter cassettes
- Filter cover glass, Removable metal grease filters
- Saturation indicator for metal and charcoal filter
Performance/technical information
- Suitable for ducted or recirculating operation
- Extraction rate according to EN 61591 ø 15 cm:
max. Normal use 480 m³/h
Intensive 850 m³/h
- Extraction rate exhaust air according to EN 61591:
max. normal use 480 m³/h, intensive 850 m³/h
- Power rating: 272 W
- Noise level according to EN 60704-3 and EN 60704-2-13 exhaust air:
Max. normal use: 62 dB(A) re 1 pW (48 dB(A) re 20 µPa sound pressure)
Intensive: 73 dB(A) re 1 pW (59 dB(A) re 20 µPa sound pressure)
- Noise max. Normal Level: 62 dB*
- Average Energy Consumption: 50.2 kWh/year*
- Energy Efficiency Class: A*
- Blower Efficiency Class: A*
- Lighting Efficiency Class: A*
- Grease Filtering Efficiency Class: E*
- Dimensions exhaust air (HxWxD): 1004-1344 x 900 x 391 mm
- Dimensions recirculating (HxWxD): 1004-1454 x 900 x 391 mm
- Dimensions recirculating with CleanAir module (HxWxD): 1199-1529 x 900 x 391 mm
- Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
- Light Intensity: 209 lux
- Colour Temperature: 4000 K
- 850bldc
Optional accessories
- For recirculated extraction recirculating kit or CleanAir recirculating kit (accessory) needed
